Introducing our fully tested and certified Fire rated parcel range – myRENZbox Modula – 2 Hour Fire Rated Parcel Boxes.
As a UK leading mail and parcel manufacturer, we invest in continuous innovation, R&D to bring new, specification led and conforming products to the market with the highest of standards.
These 2hr fire rated parcel boxes are able to contain, or, hold back a fire for 120 mins. Tested by Warrington Fire in accordance with BS EN 1363-1: 2020.
They can be installed wall mounted, wall recessed, through the wall or freestanding.
Fire Rated Parcel Box Models
Comprehensive Fire Rated Testing
The fire rated test involved removing the backs of the parcel boxes to simulate a fire inside and to the rear and to do so they were placed in a furnace which was turned up to 1064 degrees C. The test was concluded at 132 minutes, and our myRENZbox parcel boxes showed no signs of weakness or deterioration. They passed the test and are now fire rated for two hours, complying to the new BS EN 1363-1:2012 standard.
As a reliable British and trusted manufacturer we always offer additional safety advice and guidelines when using fire rated parcel boxes within a fire wall.
Full advice and guidance is offered by our team to ensure full consideration is given to the handling of these products on site.
Working with Warrington Fire
The Safety Letterbox Company R&D team worked with Warringtonfire to become the first company to achieve full 2 hour Fire Rating (integrity only) tested to BS EN 1363-1:2020. This allows both parcelboxes and mailboxes to be safely housed within a fire rated area, wall or escape route when installed in accordance with guidelines*.
*Please contact us to discuss.
BS EN 1363-1: 2020
These 2 hour Fire Rated Parcel boxes include several specially developed features to satisfy Fire Rating standards BS EN 1363-1: 2020.
This ensures the product is suitable for surface mounting, recessing or freestanding, if fitted in accordance with guidelines and located within a fire rated area.
First 120 Minute Fire Rated Parcel Boxes
myRENZbox have been fully tested in extreme conditions at Warrington Fire Research Labratory. The parcel boxes were:
- Tested for a total of 132 minutes
- BS EN 1363-1: 2020 compliant
- Class 0 fire rated compliant
- Able to contain or hold back a fire for two hours
Research and Development
Our Research and Development team worked with Exova Warrington to become the first company to achieve full Fire Rating (two hour integrity only) to BS EN 1361-1 : 2020 on this specifically created group of parcel boxes.
We continue to push the boundaries and be at the forefront of Fire Rated product advances, we are currently investing in further testing and R&D to enable us to expand the range in this area.
What is myRENZbox Modula?
Part of the Classic range, MODULA is a fully scalable intelligent parcel box system with proven functionality that is competitively priced. The combination of hardware and unique RENZ software platform enables full automation of the parcel delivery, collection and returns process.
At the ‘heart’ of this scalable system is a choice of two standalone control modules with the option of a further nine parcel extension modules. The system can be extended to manage up to 500 box compartments with electronic locks operated from a single controller.
Extension modules are simply added to the control module to match the exact project requirements. We provide guidance to help configure the specific number and size distribution of parcel boxes required for each project.
Integration with Existing Systems
In addition to the standard processes we can also provide expert technical support to integrate with building management software, electronic door entry systems and to comply with existing organisational protocols.
The MODULA Parcel box system is connected to an online software portal at www.myrenz.com. The system portal enables remote management by the system owner. Registered users can also login to a user portal to manage their individual accounts.
Designed for New Build and Retrofit Projects
Designed for both new build and retrofit projects, the MODULA System is engineered for both internal and external installation. MODULA is an ideal solution for the challenges presented by online parcel deliveries and future proofed for the challenges of tomorrow.
Modula Features
Ideal For Multi-occupancy Properties
The MODULA range of parcel boxes has been developed to securely store parcels for multi-occupancy residences.
Extendible Solution To Meet Changing Requirements
The MODULA parcel boxes can be extended by integrating additional columns of products to meet increasing parcel delivery requirements.
Delivering Efficiencies
The MODULA parcel box delivers efficiencies by minimising concierge involvement in the parcel management process.
Suitable For Both Internal and External Use
The myRENZbox Modula Parcel Box range is suitable for use in both internal and external covered locations.
Futureproofed Parcel Boxes
The myRENZbox Modula box is flexible for future software process upgrades and adding new functionality to the system.
A Flair For Design
When it comes to parcel boxes, one size doesn’t fit all. We have decades of experience in the design, manufacture and supply of both mail and parcel boxes, meaning we can tailor your intelligent parcel box to your exact needs.
myRENZbox Modula Column Options
myRENZbox Modula
Fire Rated Control Module A
myRENZbox – Intelligent Modula System, main control module. Including, The Renz 8″ Control Unit Plus with integrated parcel delivery boxes 2x XS, 1x S, 1x M, 1x XL, casing sheet steel, standard RAL Colour, Manufactured according to EN13724.
DIMENSIONS
Height: 1828mm -0/+30
Width: 533mm
Depth: 408mm
WEIGHT
Nett weight: 115kg
Gross weight: 290kg (35kg per compartment)
POWER CONSUMPTION
Hour: 35 w
Day: 840 w
Year: 306.6 kw
CAPACITY
2x XS
1x S
1x M
1x XL
| Outer Dimensions | Internal Dimensions | |
| XS | 533 x 97 x 408 | 468 x 81 x 380 |
| S | 265 | 468 x 178 x 380 |
| M | 120 | 468 x 372 x 380 |
| XL | 30H x 235W | 468 x 740 x 380 |
FINISH
RENZ Polyester Powder Coating
Standard Colours:
RAL9007 – Aluminium Grey
RAL9016 – Traffic White
Matt
Other RAL colours are available at an additional cost
BARCODE SCANNER
myRENZbox Bar Code Scanner / Reader
ZEBRA SE3307VA bar code scanner / reader integrated within control module.
MYRENZ.COM PORTAL
Accessible as a landlord account to manage the parcel box, user accounts and provide statistical reporting. Also open to registered users to manage personal myRENZbox accounts.
MYRENZBOX SERVICE TAG
A red RFID electronic chip SERVICE TAG is supplied, pre-programmed to provide management access to the service menu directly on the myRENZbox touch screen.
MYRENZBOX MOBILE APP
Free mobile app downloadable from either the ‘app store’ or ‘google play store’ & compatible with either IOS or ANDROID operating systems. myRENZbox mobile app is a registered user application for managing personal parcel deliveries & collections.
myRENZbox Modula
Fire Rated Control Module B
myRENZbox – Intelligent Modula System, main control module. Including, The Renz 8″ Control Unit Plus with integrated parcel delivery boxes 4x S, 2x M, casing sheet steel, standard RAL Colour, Manufactured according to EN13724.
DIMENSIONS
Height: 1828mm -0/+30
Width: 533mm
Depth: 408mm
WEIGHT
Nett weight: 113kg
Gross weight: 323kg (35kg per compartment)
POWER CONSUMPTION
Hour: 35 w
Day: 840 w
Year: 306.6 kw
CAPACITY
4x S
2x M
| Outer Dimensions | Internal Dimensions | |
| XS | 533 x 97 x 408 | 468 x 81 x 380 |
| S | 533 x 194 x 408 | 468 x 178 x 380 |
| M | 533 x 388 x 408 | 468 x 372 x 380 |
| XL | 533 x 776 x 408 | 468 x 740 x 380 |
FINISH
RENZ Polyester Powder Coating
Standard Colours:
RAL9007 – Aluminium Grey
RAL9016 – Traffic White
Matt
Other RAL colours are available at an additional cost
BARCODE SCANNER
myRENZbox Bar Code Scanner / Reader
ZEBRA SE3307VA bar code scanner / reader integrated within control module.
MYRENZ.COM PORTAL
Accessible as a landlord account to manage the parcel box, user accounts and provide statistical reporting. Also open to registered users to manage personal myRENZbox accounts.
MYRENZBOX SERVICE TAG
A red RFID electronic chip SERVICE TAG is supplied, pre-programmed to provide management access to the service menu directly on the myRENZbox touch screen.
MYRENZBOX MOBILE APP
Free mobile app downloadable from either the ‘app store’ or ‘google play store’ & compatible with either IOS or ANDROID operating systems. myRENZbox mobile app is a registered user application for managing personal parcel deliveries & collections.
myRENZbox Modula
Fire Rated Extension Module A
myRENZbox – Integrated parcel delivery boxes 4x XS, 1x S, 3x M. Casing Sheet steel, Standard RAL colour. 1 Control Module (A or B) is required for additional extension modules to work.
DIMENSIONS
Height: 1828mm -0/+30
Width: 533mm
Depth: 408mm
WEIGHT
Nett weight: 113kg
Gross weight: 323kg (35kg per compartment)
POWER CONSUMPTION
Hour: 5 w
Day: 120 w
Year: 43.8 kw
CAPACITY
4x XS
1x S
3x M
| Outer Dimensions | Internal Dimensions | |
| XS | 533 x 97 x 408 | 468 x 81 x 380 |
| S | 533 x 194 x 408 | 468 x 178 x 380 |
| M | 533 x 388 x 408 | 468 x 372 x 380 |
| XL | 533 x 776 x 408 | 468 x 740 x 380 |
FINISH
RENZ Polyester Powder Coating
Standard Colours:
RAL9007 – Aluminium Grey
RAL9016 – Traffic White
Matt
Other RAL colours are available at an additional cost
MYRENZ.COM PORTAL
Accessible as a landlord account to manage the parcel box, user accounts and provide statistical reporting. Also open to registered users to manage personal myRENZbox accounts.
MYRENZBOX SERVICE TAG
A red RFID electronic chip SERVICE TAG is supplied, pre-programmed to provide management access to the service menu directly on the myRENZbox touch screen.
myRENZbox Modula
Fire Rated Extension Module B
myRENZbox – Integrated parcel delivery boxes 3x S, 1x M, 1x XL. Casing Sheet steel, Standard RAL colour. 1 Control Module (A or B) is required for additional extension modules to work.
DIMENSIONS
Height: 1828mm -0/+30
Width: 533mm
Depth: 408mm
WEIGHT
Nett weight: 80kg
Gross weight: 255kg (35kg per compartment)
POWER CONSUMPTION
Hour: 5 w
Day: 120 w
Year: 43.8 kw
CAPACITY
3x S
1x M
1x XL
| Outer Dimensions | Internal Dimensions | |
| XS | 533 x 97 x 408 | 468 x 81 x 380 |
| S | 533 x 194 x 408 | 468 x 178 x 380 |
| M | 533 x 388 x 408 | 468 x 372 x 380 |
| XL | 533 x 776 x 408 | 468 x 740 x 380 |
FINISH
RENZ Polyester Powder Coating
Standard Colours:
RAL9007 – Aluminium Grey
RAL9016 – Traffic White
Matt
Other RAL colours are available at an additional cost
myRENZbox Modula
Fire Rated Extension Module C
myRENZbox – Integrated parcel delivery boxes 1x XL, 2x M, 1x S. Casing Sheet steel, Standard RAL colour. 1 Control Module (A or B) is required for additional extension modules to work.
DIMENSIONS
Height: 1828mm -0/+30
Width: 533mm
Depth: 408mm
WEIGHT
Nett weight: 77kg
Gross weight: 217kg (35kg per compartment)
POWER CONSUMPTION
Hour: 5 w
Day: 120 w
Year: 43.8 kw
CAPACITY
3x S
1x M
1x XL
| Outer Dimensions | Internal Dimensions | |
| XS | 533 x 97 x 408 | 468 x 81 x 380 |
| S | 533 x 194 x 408 | 468 x 178 x 380 |
| M | 533 x 388 x 408 | 468 x 372 x 380 |
| XL | 533 x 776 x 408 | 468 x 740 x 380 |
FINISH
RENZ Polyester Powder Coating
Standard Colours:
RAL9007 – Aluminium Grey
RAL9016 – Traffic White
Matt
Other RAL colours are available at an additional cost
myRENZbox Modula
Fire Rated Extension Module D
myRENZbox – Integrated parcel delivery boxes 2x XL, 1x S. Casing Sheet steel, Standard RAL colour. 1 Control Module (A or B) is required for additional extension modules to work.
DIMENSIONS
Height: 1828mm -0/+30
Width: 533mm
Depth: 408mm
WEIGHT
Nett weight: 75kg
Gross weight: 180kg (35kg per compartment)
POWER CONSUMPTION
Hour: 5 w
Day: 120 w
Year: 43.8 kw
CAPACITY
1x S
2x XL
| Outer Dimensions | Internal Dimensions | |
| XS | 533 x 97 x 408 | 468 x 81 x 380 |
| S | 533 x 194 x 408 | 468 x 178 x 380 |
| M | 533 x 388 x 408 | 468 x 372 x 380 |
| XL | 533 x 776 x 408 | 468 x 740 x 380 |
FINISH
RENZ Polyester Powder Coating
Standard Colours:
RAL9007 – Aluminium Grey
RAL9016 – Traffic White
Matt
Other RAL colours are available at an additional cost
myRENZbox Modula
Fire Rated Extension Module E
myRENZbox – Integrated parcel delivery boxes, narrow 300mm wide, 1 x Nxl, Casing Sheet steel, Standard RAL colour. 1 Control Module (A or B) is required for additional extension modules to work.
DIMENSIONS
Height: 1828mm -0/+30
Width: 300mm
Depth: 408mm
WEIGHT
Nett weight: 55kg
Gross weight: 90kg (35kg per compartment)
POWER CONSUMPTION
Hour: 5 w
Day: 120 w
Year: 43.8 kw
CAPACITY
1x Nxl
2x XL
| Outer Dimensions | Internal Dimensions | |
| NXS | 300 x 97 x 408 | 235 x 81 x 380 |
| NS | 300 x 194 x 408 | 235 x 178 x 380 |
| NM | 300 x 388 x 408 | 235 x 372 x 380 |
| NL | 300 x 776 x 408 | 235 x 740 x 380 |
| NXL | 300 x 1746 x 408 | 235 x 1694 x 380 |
FINISH
RENZ Polyester Powder Coating
Standard Colours:
RAL9007 – Aluminium Grey
RAL9016 – Traffic White
Matt
Other RAL colours are available at an additional cost
myRENZbox Modula
Fire Rated Extension Module F
myRENZbox – Integrated parcel delivery boxes, narrow 300mm wide, 3x NS, 1x Nm & 1x Nl, Casing Sheet steel, Standard RAL colour. 1 Control Module (A or B) is required for additional extension modules to work.
DIMENSIONS
Height: 1828mm -0/+30
Width: 300mm
Depth: 408mm
WEIGHT
Nett weight: 60kg
Gross weight: 235kg (35kg per compartment)
POWER CONSUMPTION
Hour: 5 w
Day: 120 w
Year: 43.8 kw
CAPACITY
3 x Ns
1x Nm
1x Nl
| Outer Dimensions | Internal Dimensions | |
| NXS | 300 x 97 x 408 | 235 x 81 x 380 |
| NS | 300 x 194 x 408 | 235 x 178 x 380 |
| NM | 300 x 388 x 408 | 235 x 372 x 380 |
| NL | 300 x 776 x 408 | 235 x 740 x 380 |
| NXL | 300 x 1746 x 408 | 235 x 1694 x 380 |
FINISH
RENZ Polyester Powder Coating
Standard Colours:
RAL9007 – Aluminium Grey
RAL9016 – Traffic White
Matt
Other RAL colours are available at an additional cost
myRENZbox Modula
Fire Rated Extension Module G
myRENZbox – Integrated parcel delivery boxes, narrow 300mm wide, 3x Ns & 3x Nm, Casing Sheet steel, Standard RAL colour. 1 Control Module (A or B) is required for additional extension modules to work.
DIMENSIONS
Height: 1828mm -0/+30
Width: 300mm
Depth: 408mm
WEIGHT
Nett weight: 62kg
Gross weight: 272kg (35kg per compartment)
POWER CONSUMPTION
Hour: 5 w
Day: 120 w
Year: 43.8 kw
CAPACITY
3 x Ns
3x Nm
| Outer Dimensions | Internal Dimensions | |
| NXS | 300 x 97 x 408 | 235 x 81 x 380 |
| NS | 300 x 194 x 408 | 235 x 178 x 380 |
| NM | 300 x 388 x 408 | 235 x 372 x 380 |
| NL | 300 x 776 x 408 | 235 x 740 x 380 |
| NXL | 300 x 1746 x 408 | 235 x 1694 x 380 |
FINISH
RENZ Polyester Powder Coating
Standard Colours:
RAL9007 – Aluminium Grey
RAL9016 – Traffic White
Matt
Other RAL colours are available at an additional cost
myRENZbox Modula
Fire Rated Extension Module H
myRENZbox – Integrated parcel delivery boxes 3x S & 3x M. Casing Sheet steel, Standard RAL colour. Overall Height 1828mm +0/+30, Width 533mm, Depth 408mm. 1 Control Module (A or B) is required for additional extension modules to work.
DIMENSIONS
Height: 1828mm -0/+30
Width: 533mm
Depth: 408mm
WEIGHT
Nett weight: 113kg
Gross weight: 323kg (35kg per compartment)
POWER CONSUMPTION
Hour: 35 w
Day: 840 w
Year: 306.6 kw
CAPACITY
4x S
2x M
| Outer Dimensions | Internal Dimensions | |
| XS | 533 x 97 x 408 | 468 x 81 x 380 |
| S | 533 x 194 x 408 | 468 x 178 x 380 |
| M | 533 x 388 x 408 | 468 x 372 x 380 |
| XL | 533 x 776 x 408 | 468 x 740 x 380 |
FINISH
RENZ Polyester Powder Coating
Standard Colours:
RAL9007 – Aluminium Grey
RAL9016 – Traffic White
Matt
Other RAL colours are available at an additional cost
BARCODE SCANNER
myRENZbox Bar Code Scanner / Reader
ZEBRA SE3307VA bar code scanner / reader integrated within control module.
MYRENZ.COM PORTAL
Accessible as a landlord account to manage the parcel box, user accounts and provide statistical reporting. Also open to registered users to manage personal myRENZbox accounts.
MYRENZBOX SERVICE TAG
A red RFID electronic chip SERVICE TAG is supplied, pre-programmed to provide management access to the service menu directly on the myRENZbox touch screen.
myRENZbox Modula
Fire Rated Extension Module I
myRENZbox – Integrated parcel delivery boxes, narrow 300mm wide, 12x Nxs, 1x Ns & 1x Nm, Casing Sheet steel, Standard RAL colour. 1 Control Module (A or B) is required for additional extension modules to work.
DIMENSIONS
Height: 1828mm -0/+30
Width: 533mm
Depth: 408mm
WEIGHT
Nett weight: 70kg
Gross weight: 350kg (35kg per compartment)
POWER CONSUMPTION
Hour: 5 w
Day: 120 w
Year: 43.8 kw
CAPACITY
12x Nxs
1x Ns
1x Nm
| Outer Dimensions | Internal Dimensions | |
| NXS | 300 x 97 x 408 | 235 x 81 x 380 |
| NS | 300 x 194 x 408 | 235 x 178 x 380 |
| NM | 300 x 388 x 408 | 235 x 372 x 380 |
| NL | 300 x 776 x 408 | 235 x 740 x 380 |
| NXL | 300 x 1746 x 408 | 235 x 1694 x 380 |
FINISH
RENZ Polyester Powder Coating
Standard Colours:
RAL9007 – Aluminium Grey
RAL9016 – Traffic White
Matt
Other RAL colours are available at an additional cost
Parcel Box Projects
No-obligation consultation
We welcome the chance to discuss your project and we can share all that is current in terms of standards and product options totally free of charge.
Simply complete and submit the form and we will get back in touch to talk through your requirements.
We also provide Autocad drawings as required – it’s all part of the service!
